Apache Flink, Kubernetes, and How It Works

Imagine you have a factory that processes things. Flink is like that factory, and Kubernetes is like the factory floor manager that decides where machines go and how they run.

---

1. What is Flink?

Apache Flink is a distributed data processing engine.

• “Distributed” means it can run across multiple computers (nodes) at the same time.

• “Data processing” means it takes data streams or batches and transforms them into results.

• It can process data as it arrives (streaming) or process a fixed dataset (batch).

• Flink is stateful and fault-tolerant: it remembers important information and can recover if a worker dies.

Example:

Like counting how many people enter a mall every minute:

• Flink will keep a running total.

• If a computer crashes, it will recover the total from where it left off.

---

2. Flink Cluster Components

A Flink cluster has two main roles:

JobManager (JM): The Brain

• The JobManager is like the manager of the factory.

• Responsibilities:

  • Accept jobs (the “instructions” for the factory)

  • Split the job into smaller tasks

  • Decide which worker (TaskManager) will execute each task

  • Keep track of the state and checkpoints

  • Handle failure recovery

• Usually, 1 JobManager pod in Kubernetes

• Needs persistent storage (PVC) because it stores checkpoints and savepoints

---

TaskManager (TM): The Worker

• The TaskManager is like a worker machine on the factory floor.

• Responsibilities:

  • Execute tasks assigned by the JobManager

  • Keep temporary state in memory or local disk (ephemeral)

  • Report back progress to JobManager

• TaskManagers are stateless and ephemeral:

  • If a TaskManager dies, Kubernetes will restart it somewhere else

  • JobManager uses checkpoints to restore the state

• Each TaskManager pod can have one or more slots (think “hands” to do work)

---

3. Slots: Hands of the TaskManager

• Each TaskManager has slots, which are units of parallel work.

• Each slot can run one subtask of a Flink job.

Analogy:

• Imagine a worker has 2 hands → they can work on 2 small tasks at the same time

• If you have 4 workers, each with 2 hands → 8 tasks can be worked on simultaneously

• Slots allow Flink to divide work and control resources (memory, CPU) per task

---

4. Parallelism: How Many Hands Work

Parallelism is how many subtasks a job is divided into.

• Each subtask needs one slot.

• Maximum parallelism = total slots in cluster

Example:

• parallelism.default = 2 → job will run 2 subtasks if no -p is specified

• Job parallelism = 6 → 6 subtasks run, distributed across the 4 TaskManagers

• Job parallelism = 10 → only 8 subtasks can run at once (total slots), 2 wait

---

5. How TaskManagers store data

• TaskManagers are ephemeral; they use local memory or local disk for temporary state.

• They do NOT use PVC. If a TaskManager dies, its data is lost.

• JobManager + PVC is where durable state lives:

  • Checkpoints

  • Savepoints

Checkpoint flow:

1. JobManager asks TaskManagers to snapshot their local state

2. TaskManagers send snapshots to JobManager

3. JobManager writes snapshots to PVC (persistent storage)

4. If a TM dies, it is restarted → state is restored from PVC

---

6. How Kubernetes schedules TaskManagers

As an example, let us see this scenario:

• You requested 4 TaskManager pods

• Kubernetes decides which node each pod runs on

• You added soft anti-affinity → tries to spread them across both nodes

Example of your cluster after scheduling:

• JobManager pod runs on node1, mounts PVC for persistent storage

• TaskManagers use local ephemeral storage

---

7. Step-by-step of job execution

1. Submit a job (example: WordCount)

2. JobManager splits job into subtasks according to parallelism

3. Assigns subtasks to TaskManager slots

4. TaskManagers execute tasks, keep temporary state

5. Periodically, TaskManagers checkpoint state to JobManager → written to PVC

6. If a TaskManager dies → Kubernetes restarts pod → JobManager restores state

7. Job continues processing seamlessly

---

8. Example analogy

• JobManager → Manager in a factory

• TaskManagers → Workers on the floor

• Slots → Worker’s hands

• Parallelism → Number of hands used on a job

• PVC → Manager’s filing cabinet with important records

• TaskManager ephemeral storage → Paper on worker’s desk (temporary, lost if worker leaves)

---

Key takeaways

• Flink separates computation (TaskManagers) from state (JobManager + PVC)

• Slots control parallelism at runtime

• TaskManagers are disposable, Kubernetes can reschedule them anywhere

• JobManager is critical: PVC ensures job can recover if TMs die

• Parallelism.default is just a default; maximum parallelism is determined by total slots in cluster
