Monitoring brainwave activity in real time has always fascinated me. I wanted to build something that could collect EEG signals, process them on a lightweight device, and display the results on a clean web dashboard. With an ESP32, a MAX30100 sensor, a small analog EEG input, and a FastAPI backend, I was able to create a portable system that measures Alpha, Beta, and Gamma brainwave bands and visualises them as simple bar graphs.

This article explains how I built the entire pipeline, from data collection to real-time visualisation.

I also wrote a short study based on this and used M5Stack for it:
https://www.researchgate.net/publication/391839761_Short-Term_Neurophysiological_Changes_During_Transcendental_Meditation_A_Pilot_EEG_and_ECG-Based_Study

---

Why I Built This

I wanted a portable and affordable setup that could:

• Collect EEG data through a simple analog pin

• Compute frequency bands using Fast Fourier Transform

• Add additional biometric data from a MAX30100 sensor

• Send all readings to a backend server over Wi-Fi

• Show clean and simple charts on a dashboard

• Make the system completely wireless

The ESP32 Zero 2 WH (or any small ESP32 board) was perfect because it is inexpensive, efficient, and supports both Wi-Fi and continuous sensor sampling.

---

Hardware Setup

Components Used

• ESP32 (M5Core2 or Zero 2 WH)

• MAX30100 sensor for infrared and red readings, later used ECG Module

• EEG analog signal (BioAmpEXG Pill) connected to an ADC pin

• Wi-Fi to push data to backend

• Power source (USB or portable battery)

Wiring Overview

• MAX30100 SDA → ESP32 SDA pin

• MAX30100 SCL → ESP32 SCL pin

• EEG analog output → ESP32 ADC pin

• Common ground for all components

The MAX30100 is optional for brainwave detection, but I wanted additional IR/RED data to calculate orderliness and signal health. This was the initial choice, but later I switched to AD8232

---

ESP32 Firmware Logic

The ESP32 collects data continuously. Each cycle does the following:

1. Read raw EEG analog values

2. Read IR and RED values from MAX30100

3. Apply Fast Fourier Transform to EEG samples

4. Extract band powers:

   • Alpha (8 to 12 Hz)

   • Beta (12 to 30 Hz)

   • Gamma (30 to 100 Hz)

5. Package everything into a JSON payload

6. Send the JSON data to the FastAPI backend via Wi-Fi

Example JSON Payload

{
    "alpha": 42.3,
    "beta": 28.1,
    "gamma": 10.5,
    "orderliness": 0.82,
    "ir": 51200,
    "red": 50390
}

---

Backend: FastAPI Application

The backend receives data, stores it, and serves it to the dashboard.

Key Features

• Endpoint for receiving ESP32 JSON data

• In-memory store or Redis for fast access

• REST endpoint for the dashboard

• CORS enabled

• Very low latency

Example FastAPI Endpoint

from fastapi import FastAPI
from pydantic import BaseModel

class BrainwaveData(BaseModel):
    alpha: float
    beta: float
    gamma: float
    orderliness: float
    ir: int
    red: int

app = FastAPI()

latest_data = BrainwaveData(
    alpha=0, beta=0, gamma=0, orderliness=0, ir=0, red=0
)

@app.post("/update")
def update(data: BrainwaveData):
    global latest_data
    latest_data = data
    return {"status": "ok"}

@app.get("/data")
def get_data():
    return latest_data

---

Building the Dashboard

I wanted a clean visualisation with no curves, only bar graphs.
The dashboard uses:

• HTML + Bootstrap

• Chart.js for bar charts

• Auto-refresh using JavaScript

• Smooth transitions

Why Bar Graphs?

Bar graphs work well because brainwave bands are relative.
The magnitude of Alpha versus Beta is the most important insight, and bars make comparison easy.

---

Dashboard Layout

The dashboard has:

• A bar graph for Alpha, Beta, and Gamma

• A card showing orderliness

• A small panel showing IR and RED values

• A refresh interval of 1 second

Example Chart.js Code Snippet

const ctx = document.getElementById("brainChart");

const chart = new Chart(ctx, {
    type: "bar",
    data: {
        labels: ["Alpha", "Beta", "Gamma"],
        datasets: [{
            data: [0, 0, 0]
        }]
    },
    options: {
        animation: false,
        scales: {
            y: { beginAtZero: true }
        }
    }
});

async function refreshData() {
    const r = await fetch("/data");
    const d = await r.json();
    chart.data.datasets[0].data = [d.alpha, d.beta, d.gamma];
    chart.update();
}

setInterval(refreshData, 1000);

Here is a graph that I obtained:

---

How It Works Together

End-to-End Pipeline

1. ESP32 reads EEG values and MAX30100 values

2. ESP32 performs FFT and computes band powers

3. ESP32 sends JSON to FastAPI backend

4. Dashboard fetches latest data through /data

5. Chart.js updates the bars in real time

---

Challenges I Faced

1. Noise in the EEG Signal

Low-cost EEG is noisy.
I had to apply:

• Moving average filters

• Calibration

• Proper grounding

• FFT windowing

2. Sampling Rate Stability

To extract accurate brainwave bands, the sampling rate must be stable.
I locked the ESP32 ADC sampling to a consistent interval.

3. Fast Refresh Rendering

Continuous updates caused stuttering until I disabled animation in Chart.js.

---

Final Result

The dashboard provides a clean and real-time visualisation of:

• Alpha, Beta, Gamma brain activity

• Signal orderliness

• Infrared and red biometric data

It works smoothly on both desktop and mobile browsers and updates once every second.

---

Future Improvements

I plan to enhance the system with:

• WebSocket streaming instead of polling

• A rolling timeline view for long sessions

• Support for multiple users

• A database for storing and analysing sessions

• A machine learning model that detects focus, stress, or calmness

---

Conclusion

This project showed me how much can be done with simple hardware and a clean backend architecture. By combining an ESP32, BioAmpEXG, FFT analysis, FastAPI, and a lightweight dashboard, it is possible to create a fully portable and real-time brainwave monitoring system.
